DC-5M optical transceiver module
Parameters of the transceiver link：
| Part No. | Data Rate | Fiber Length | Supply Voltage | Propagation Delay LOW to HIGH |
Propagation Delay HIGH to LOW |
|---|---|---|---|---|---|
| NRS1521ETZ/2521ETZ | DC-5MBd | 80m | 5V | 47ns | 42ns |
| NRS1521CZ/2521CZ | DC-5MBd | 110m | 3.3V/5V | 29ns | 32ns |
Transmitter performance parameters：
| Part No. | Operating Temperature | Peak Emission Wavelength |
Forward Voltage | Output Power 1mm POF IF=60mA |
Output Power 1mm POF IF=30mA |
|---|---|---|---|---|---|
| NRS1521ETZ | -40 ~ 85℃ | 650nm | 2V | -5dBm | - |
| NRS1521CZ | -40 ~ 85℃ | 650nm | 1.95V | - | -2dBm |
Receiver performance parameters：
| Part No. | Data Rate | Operating Temperature | High Level Supply Currnet | Low Level Supply Currnet | Peak Optical Input Power Logic Level Low |
|---|---|---|---|---|---|
| NRS2521ETZ | DC-5MBd | -40 ~ 85℃ | 5.2mA | 5.3mA | -24dBm |
| NRS2521CZ | DC-5MBd | -40 ~ 85℃ | 6mA | 6mA | -24dBm |
![]()
![]()
